Belt conveyors works under the effect of friction force. The motor drives the driving roller of the belt conveyor, then roller will drive the belt moving accordingly, the materials are conveyed from the original place to the place where they are needed.
Features:
ribbon conveyer 1.The general fabric conveyor belt is made of EP, NN or Cotton fabric and finished through the processes of calendering, firming and vulcanizing, etc; 2.It facilitates goods handling work and also provides advantages to advanced production,modernized management and safe operation; 3.More than 200 Libo belt conveyors are operating worldwide. Maximum horizontal curve angle of 47.7 Degree,minimum curve radius 120m, and maximum No. of curves of 10 ; 4.Large transport capacity, long-distance, but also it is widely used.in the transportation process while completing a number of process operation; 5.The belt conveyor can be installed horizontally or a slope to meet the needs of different transfer lines; 6.Introduced high strength aluminum alloy manufacturing ,anodization of stand blast ,elegant appearance; 7.Without cleaning device at outlet, low noise, flexible arrangement on position of inlet and outlet.
Technical parameters of ribbon conveyer:
Belt Width
(mm)
Belt Length(m) / Power(kw)
Belt Speed
(m/s)
Capacity
(t/h)
B400
≤12/1.5
12-20/2.2
20-25/3
0.8-2
40-80
B500
≤12/3
12-20/4
20-30/5.5
0.8-2
78-191
B650
≤12/4
12-20/5.5
20-30/7.5
0.8-2
131-323
B800
≤10/4
10-15/5.5
15-25/7.5
1.0-2
278-546
B1000
≤10/5.5
10-20/7.5
20-25/11
1.0-2
435-853
B1200
≤10/7.5
10-20/11
20-25/15
1.0-2
655-1284
