Product Description

SPECIFICATIONS

Capacity: 4.72" x .157" (Maximum)
Number of Hardened Straightener Rolls: 21
Diameter of Straightening Rolls: .94"
Feed Rate: Variable
Adjustable Upper Straightener Rolls
All Straightener Rolls Power Driven
Rolls Backed-Up Top & Bottom
Direction of Feed: R - L
EQUIPPED WITH:

Programmable Control System
(5") Entry Single Roll Power Feeder w/Loop Control
Power Roller Frame Adjustment
Adjustable Stock Entry/Exit Guides w/Digital Read-Out
Digital Rolls Position Indicators
Automatic Lubrication System
Electrical Vari-Speed Drive
Electrical Controls

Approximate Overall Dimensions:     100" L-R x 90" F-B x 88" H
Approximate Weight:       5,000 Lbs
