181hp 17500kg mini bulldozer DK160

Quick Details

Place of Origin:Guangdong, China (Mainland)
Brand Name:DK
Model Number:160
Condition:New
Moving Type:crawler dozer
Machine Weight:17500kg
Dimension(Long * Breadth * High):5245mm,3447mm,3040mm
Engine rated power:132kw
Engine rated speed:2000r/min
Dozer 160 Track width:500mm
Mini dozer Track gauge:1880mm
Max.lifting height f dozer shovel:915mm

Packaging & Delivery

Packaging Details:	40 size container
Delivery Detail:	within 20days

Specifications

181hp 17500kg mini bulldozer DK160
1,Horse power:181hp
2,Operating weight:17500kg
2,5245,3447,3040(mm )

181hp 17500kg mini bulldozer DK160
YTO engine,British technology
Max towing force ¡Ý146KN
4F+2R mechanical gearbox
Hydraulic steerin

bulldozer price: lowest

Model		DK160
Total weight	kg	17500(tilt dozer)
Max towing force	kN	¡Ý146
Horse power		160PS
Engine rated power	kw	132
Engine rated speed	r/min	2000
Fuel Consumption of the engine	g/kw.h	¡Ü235
Engine max torque	N.m	526
Traveling speed	km/h
Forward V gears	km/h	2.4~10.6
Reverse IV gears	km/h	3.8~7.0
Max slope angle	o
Caterpillar track board width	mm	500
Land pressure	Kpa	51/58(tlt dozer)
Overall length	mm	5245
Overall width	mm	3447(tilt dozer)
Overall height	mm	3040
Blade width	mm	3447(tilt dozer)
Blade height	mm	1167(tilt dozer)
Blade max lifting height	mm	915
Blade max digging depth	mm	400
Cutting angle(adjustable)	o	55
Towing equipment/Scar fier (Optional ripper)		Fixed type/three teeth

Dozer (Industrial type)

1) Engine: Choose the pressure rising engine produced with British Ricardo joint-venture technology, lower oil consumption, stronger torsion.

2) Main clutch comprises of dry,dual-sheet and common cornbined with,features bigger torque reserye,simpler construction,more reliable and easier maintenance.

3) Gear box is applied to 4F plus 2R mechanical shift,features higher efficiency,simpier operation,easier maintenance and more reliable operation.

4) Turning clutchChoose dry and multi-piece turning clutch,manually operating with hydraulic pressure,easily meintaining,lightly and conyeniently operating.

5) Filter applied in desert is more applicable for coal reserye site,deserl and other special work condition.

6) Operation environment is fuily closed,hexahedral cab with Iower noise;effectively reducing noise beside your ear,extending your visual field and effectively improving comfort;

7) Electric system is characterized by electronic monitor, making real-time monitor for complete machine oassure normal operation

8) Standard heating and ventilation equipment, air conditioner optional.

9) Operation device:several devices such as direct-pouring shovel,envi ronmentally hygienic,angle shovel,coal-pushed shovel and soil scarfier are available for user
